388h backhoe loader
Lub 388H Backhoe Loader belongs rau lub cim tshiab ntawm Shanmon Backhoe Loaders, uas yog tsim rau Lavxias kev ua lag luam nrog ntau nrhav. Lub zog txhawb nqa thav duab thiab haib yuchai diesel cav muaj peev xwm ntau lub zog, thaum lub sij hawm plaub lub log tsim Axles ua rau 388h ntau ruaj khov thiab hloov tau. 388H tau tsim kho nrog cov kev xav tau tsis tu ncua ntawm cov neeg yuav khoom los ntawm thoob plaws lub ntiaj teb, lub hwj chim thiab ib txoj haujlwm nyuaj tshaj plaws. Txawm hais tias koj thauj cov tsheb thauj khoom, busting nce dubtop, tso cov yeeb nkab, khawb cov ntaub qhwv, lossis txav cov ntaub ntawv, 388H backhoe loader yog ntau dua li lub luag haujlwm.Ntawm no yog qhov tshwj xeeb:
| Tag nrho qhov ntev | Kev khiav hauj lwm hnyav | 10500kg |
| Zuag qhia tag nrho (L × W × H) | 6450 × 2530 × 3120mm | |
| Log puag | 2 335mm | |
| Log tread | 2050 hli | |
| Av tshem tawm | 450 hli | |
Ua yeeb yam | Loader Thoob muaj peev xwm | 1.2m³ |
Loader breakout quab yuam | 47kn | |
Loader Lifting peev | 2500 KG | |
Loader dumping qhov siab | 3050 hli | |
Loader Dumping Mus Txog | 8 70mm | |
LOADER KHO NQE | 52mm ua | |
BACKHOE STIDE muaj peev xwm | 0.3m³ | |
Backhoe thoob khawb lub zog | 50kn | |
Backhoe viav vias lub | 180 degree | |
Backhoe dumping qhov siab | 4 050mm | |
Backhoe max khawb qhov tob | 3 820mm | |
Max. traction quab yuam | 86 kn | |
Cav | Tus qauv | Yuchai YC4A105Z-T20 |
Hom | Turbocharging plaub-mob stroke | |
Kheej kheej Intern * Stroke | 4-108×132 | |
Rated zog | 75KW/100HP TSI | |
Nyob ceev | 2200R / min | |
Min. Roj noj | 230g / kw.h | |
Max.Torque | 400N.m | |
Kev khiav tawm | 4.8L | |
| Kauj System | Hom | Hydraulic Steering |
| Diverter qauv | Bzz 5-250 | |
| Pump xa | 63ml / r | |
| Lub kaum sab xis | ± 35 degree | |
| Min. tig radius | 6950mm | |
| Tsav Qag | Tus qauv | WZL100DF |
| Chaw tsim tshuaj paus | Tuam Tshoj qag | |
| Max. Thauj khoom ntawm cov qag pem hauv ntej | 13 ton | |
| Max. load ntawm rear qag | 13 TUJ | |
| Kev tiv tauj | Gearbox | Mechanically ua haujlwm Hydraulic Synchrinized ua haujlwm |
| Tus qauv | ZL 30 | |
| Zog | 4 rau pem hauv ntej thiab 4 rov qab iav | |
| Hydraulic torque converter | Lus320 | |
| Inlet Siab | {{0 {0}}. {4-0. 65mpa | |
| Qhov hluav taws xob siab | 1.6-1.9Mpa | |
| Cua txias hom | roj-txias presssure ncig | |
| Pump xa | 40 ml / r | |
Lub log | Pem Hauv Ntej Log Loj | 16.9-28 |
Lub log tsheb loj | 16.9-28 | |
Pem Hauv Ntej Log Siab | 0. 35MPA | |
Lub Tsheb Tiab Siab | 0. 35MPA | |
Mus Ncig Ceev | 38km / h | |
| Cav Nres | Kev Pabcuam Nres | Roj thawb cov roj, ua-hauv-selfregulation, tus kheej tshuav nyiaj li cas |
| Nres nres | Kev ceev nres | |
| Qhov Txheej Txheem Siab | Chaw thau khoom hydraulic system | 20MPA |
| Kev khawb hydraulic system | 20 Mpa | |
STEELING HYDRAULIC system | 14MPA |
