Carraro Axles Backhoe Loader
Lub 388T backhoe loader yog ib qho kev txhim kho zoo heev ntawm shanmon 388 backhoe loader. Lub tshuab no siv ntau yam khoom siv thoob ntiaj teb, suav nrog Italian Carraro qag, Carraro kis lub thawv, Weichai lossis Cummins diesel cav. Piv nrog rau 388, Carraro axles txais kev tsav tsheb ntub, ua rau kev tsav tsheb ntau dua thiab ua haujlwm yooj yim dua. shanmon 388T muaj plaub lub zog rau pem hauv ntej thiab plaub lub zog rov qab, thiab kev mus ncig ceev yog 38 Km / h. Nrog muti-purpose thoob thiab hloov pauv hloov pauv,388Tyuav yog pob txha ntawm kev tsim kho kev lag luam. Nov yog qhov specification:
| Zuag Tawm Ib Zos | Qhov hnyav ua haujlwm | 8 200 KG |
| Zuag qhia tag nrho qhov ntev (L × W × H) | 6050 × 2465 × 3100 hli | |
| Log Hauv | 22 80mm | |
| Log Tread | 1 785mm | |
| Av Clearance | 300mm | |
|
Ua yeeb yam |
Loader thoob muaj peev xwm |
1.0m³ |
|
Loader breakout quab yuam |
47kn |
|
|
Loader lifting muaj peev xwm |
5000kg |
|
|
Loader pov tseg qhov siab |
2760mm |
|
|
Loader dumping ncav cuag |
900mm |
|
|
LOADER KHO NQE |
52mm ua |
|
|
BACKHOE STIDE muaj peev xwm |
0.3m³ |
|
|
Backhoe thoob khawb lub zog |
50 KN |
|
|
Backhoe viav vias lub |
180 degree |
|
|
Backhoe dumping qhov siab |
3795mm |
|
|
Backhoe max khawb qhov tob |
4085 hli |
|
|
Max. traction zog |
60 KN |
|
|
Cav |
Tus qauv |
Weichai WP4G95E221 |
|
Ntaus |
Turbocharging plaub-mob stroke |
|
|
Kheej kheej Intern * Stroke |
4-105×130 |
|
|
Rated zog |
70kw / 95hp |
|
|
Rated ceev |
2200R / min |
|
|
Min. Kev siv roj |
230g / kw.h |
|
|
Max.Torque |
380N.m |
|
|
Kev khiav tawm |
4.5L |
|
| Kauj System | Hom | Lub Tsheb Hydraulic Kauj |
| Diverter qauv | BZZ5-250 | |
| Pump xa | 63ml / r | |
| Puag ncig | 36 Degree | |
| Min. tig radius | 6581 hli | |
| Tsav Qag | Tus qauv | 26.2-1920/28.43M-1654 |
| Chaw tsim tshuaj paus | Ltalis carraro | |
| Max. Thauj khoom ntawm cov qag pem hauv ntej | 22,5 t | |
| Max. load ntawm rear qag | 18.75 TUJ | |
| Kev tiv tauj | Gearbox | Countershaft PowersShift |
| Qauv | TLB1-4WD | |
| Zog | 4 Forward thiab 4 Rov Qab Txiaj Ntsig | |
| Hydraulic torque converter | carraro | |
| Inlet Siab | - | |
| Qhov hluav taws xob siab | 1.3-1.55Mpa | |
| Txias hom | roj-txias presssure ncig | |
| Pump xa | 40 ml / r | |
|
Lub log |
Pem hauv ntej log loj |
14-17.5 |
|
Lub log tsheb loj |
19.5L-24 |
|
|
Pem hauv ntej lub log siab |
0.4Mpa |
|
|
Lub Tsheb Tiab Siab |
0. 35MPA |
|
|
Kev ceev ceev |
38km / h |
|
| Nres system | Kev pabcuam nres | Ntub Sab hauv kev cai tus kheej, tus kheej tshuav nyiaj li cas |
| Nres nres | Los ntawm phau ntawv nres | |
| Qhov system siab | Chaw thau khoom hydraulic system | 20 Mpa |
| Kev khawb Hydraulic System | 20 Mpa | |
|
STEELING HYDRAULIC system |
14MPA |
