5 Tuj Shovel Loader
5 tuj shovel loader yog ib yam ntawm cov khoom hnyav siv hauv kev tsim kho kom txav los yog thauj khoom xws li av thiab pob zeb.5 tuj shove loader yog tsim los rau kev tsim kho, mining thiab lwm yam.Nws yog kev cuam tshuam ntawm 3.0m³ pem hauv ntej mounted thoob.Txhua tus ncej ntawm peb 5 tuj shovel loader yog ua los ntawm manganese ntau zog thiab ua haujlwm zoo. li qub yog tsim los ntawm thawj -chav kawm factories.Qhov kis tau tus mob yog Hangzhou Advance los yog Beilian.Cov ncej tag nrho yog ua los ntawm manganese hlau uas ua rau tag nrho lub tshuab muaj zog thiab ruaj khov thaum ua haujlwm nws.Our 5 tuj shovel loader muaj kev pab cuam lub neej, siab txoj kev nqa peev xwm thiab siab ua hauj lwm ceev.The modular radiator tuaj yeem lav 24 xuab moos ntawm kev ua haujlwm tsis cuam tshuam.
| Kev ua tau zoo | Loader lifting muaj peev xwm | 5000 KG |
| Ua haujlwm hnyav | 16 500 KG | |
| Rated thoob muaj peev xwm | 3m³ | |
| Max. zog tractive | 1 67 KN | |
| Max. lub zog tawg | 1 77 KN | |
| Max. qib muaj peev xwm | 30 degree | |
| Max. pov tseg qhov siab | 3100 hli | |
| Max. pov tseg ncav cuag | 1250 hli | |
| Zuag qhia tag nrho (L × W × H) | 8108 × 2950 × 3450mm | |
| Min. tig radius | 6 640mm | |
| Cav | Qauv | Weichai WD10G220E23 |
| Hom | Inline, dej-txias, plaub stroke | |
| Lub tog raj kheej-Inner diameter × stroke | 6-126 × 130mm | |
| Rated zog | 162 KW TSI | |
Qhov siab tshaj plaws torque | 980N.m | |
Tsawg roj-siv piv | Tsawg dua lossis sib npaug li 213g / kw.h | |
Qhov system kis | Torque converter | YWJ 315 |
Gearbox hom | ntiaj chaw | |
iav hloov | 2 mus rau pem hauv ntej thiab 1 thim rov qab hloov | |
Qhov ceev tshaj plaws | 38 km / h | |
| Tsav axles | Log puag | 3 250mm |
Log tread | 2250 hli | |
Av clearance | 450 hli | |
| Hydraulic system | Qhov system ua haujlwm siab | 18 Mpa |
| Boom lifting lub sij hawm | 5.95±0.2s | |
| Tag nrho lub sijhawm | 10.95±0.5s | |
| Roj tank peev xwm | 249L | |
| Tus kheej -levelling thoob | yog | |
| Nres system | Kev pabcuam nres | Cua pab disc nres ntawm 4 lub log |
| Nres nres | Kev ceev nres | |
| Lub log | Tyre specification | 23.5-25 |
Pem hauv ntej lub log siab | 0.4Mpa | |
Lub log tsheb siab | 0.35 Mpa |
